Ceiling Tile Style Rigid Panel Variable White 300MM X 1200MM

24VWW26CW603001200
LED Fixture
$354.38

UPDATED PANEL FOR 2020 INCLUDING HIGHER OUTPUT AND MODIFIED PANEL SIZES INCLUDING TWO NEW SLIM PANELS - 6"X4' AND 1'X4' AND 2'X4'

A highly durable, light-weight and slim  2' x 4' X 0.4" (603mm X 1213mm X 11.5MM) panel that is designed to fit into existing drop ceilings.
Bi-colour panels are typically stocked however the remaining items are non-stock.  Please call to inquire about availability.  Typical lead time is 4-6 weeks.



SPECIFICATIONS

Product Type : 1'x4' Bi-Color 2600k - 6000k
Product Code : 24VWW26CW603011213
CRI : ≥95
Kelvin : 2600-6000k
Mounting Type : Suspension Mount Bracket OR Recessed
Current, Rating : 3A / panel
Voltage : 24 VDC
Wattage : 36W / Channel
70W / Panel
CC / CV : Constant Voltage
IP Rating : IP50
Lumens @ Full : 5070
Lumen / Watt : 60-65 lm / w
Lifetime* : 30,000 hours
Number of Contacts : 3
LED Type : 2835
Copper Quantity : 2 Oz.
Temperature, Operating, Maximum : 70 C
Temperature, Operating, Minimum : -40 C
Agency Ratings : UL - Pending, CE, RoHS
PCB Width : 8MM
Maximum Recommended Length : N/A
Beam Angle : 170 degree
Weight : 3.6 lbs
