Sold Out
OWA IP67 Power Supplies 12VDC 90 Watt MWL-OWA90U12R7B
MWL-OWA90U12R7B
Power Supplies
$55.63
Extremely reliable and robust medical-grade power supply. Perfect for on-camera and constant-on use with our FlexLED Tape and any 24V DC LED product. Class II & Class 2 safety ensures short-circuit, overload, and over-voltage protection. Safe, powerful, and reliable are the cornerstones of our the OWA line of power supplies from Mean Well. Comes with a standard 2-prong North American input power plug.
Output plug for 60W version is a standard DC Barrel Connector (P1M)
Output plug for 90W version is standard DC Barrel Connector (P1M) or R7B locking 4-pin DIN connector
Output plug for 120W version is a locking 4-pin DIN connector (R7B)
- Output 60W / 90W / 120W
- Class II
- Class 2 (60W @ 12V & 60W @ 24V & 90W @ 24V)
- Fanless Design
- UL Listed, suitable for dry & damp locations
- 5 year warranty
- 91% high efficiency
- Mounting Holes
Specifications
| Technical data | |
|---|---|
|
Brand
|
Mean Well
|
|
Item number
|
OWA-90E-12
|
|
Series
|
OWA-90E
|
|
Description
|
AC-DC Single output moistureproof adaptor with PFC; Input 2 pin Euro plug; Output 12VDC at 7.5A with XLR 4P plug; Plastic case; Class II
|
|
Application
|
Household EN 60335
|
|
Technology
|
AC/DC
|
|
Power Format
|
Box Type - Enclosed
|
|
Output Power (W)
|
90
|
|
Output Voltage (V)
|
12
|
|
Output Current (A)
|
7.5
|
|
Input Voltage (V)
|
90 - 264
Universal Input 110/230V
|
|
IP Rating
|
IP20
IP21
IP30
IP40
IP42
IP50
IP64
IP65
IP66
IP67
|
|
Width (mm)
|
63
|
|
Height (mm)
|
37.5
|
|
Depth (mm)
|
171
|
|
Dimming Technology
|
No Dimming
|
