Pixel FlexLED 12V Individual Chip Control Indoor Bare end wires 96 LEDs/Meter I12VRGB480GS8208-B

I12VRGB480GS8208-B
LED Tape
$268.58
$268.58

48 & 72 & 96 LED/Meter RGB PixelFlex LED Tape in 12V DC

A worlds first! Pixel FlexLED individually controlled and individually cuttable in 12VDC.
This Pixel FlexLED operating 12 VDC allows for longer runs of LED while still allowing for dazzling effects and endless possibilities.
Control these strips with our PixlArt 416 controller via ArtNet or sACN data signals.
Suitable for on-camera use and flicker-free up to 240 fps at most camera settings. 8KHZ operating frequency.

Soldering Guidelines:
Soldering iron should be between 360°C and 372°C.  Please ensure not to heat each solder pad for longer than 3 seconds otherwise separation of the solder pads can occur.

Indoor and weatherproof strips have 3M double-sided tape on the back which makes installation as easy as peel n stick.

Waterproof must be mounted using silicone glue or similar.
Controller, power supply and extension cables sold separately
Quantity discounts and custom color temperatures available.

SPECIFICATIONS - INDOOR PRODUCT



Product Type : 96 LED/meter
Product Code : I12VRGB480GS8208-B
CRI : N/A
Kelvin : N/A
PCB Color : Black
Current, Rating : 2.4 A / meter
Nominal Voltage : 12 VDC
Voltage Range : -0.4 ~ 14 VDC
Wattage : 28.8 W / meter
CC / CV : Constant Voltage
IP Rating : IP43
Lumens @ Full : 1500 lm / meter
Lumen / Watt : 75
Lifetime* : 40,000 hours
Cutting Length : Individual LED
LED Quantity : 96 LED / meter
Number of Contacts : 4
LED Type : GS-8208
Copper Quantity : 3 Oz.
Temperature, Operating, Maximum : 70 C
Temperature, Operating, Minimum : -40 C
Agency Ratings : UL - E489028, CE, RoHS
PCB Width : 12 MM
Maximum Recommended Length : 5 meters
Viewing Angle : 120 degree
Adhesion : 3M 300MP
Wavelength A : 620 ~ 625nm
Wavelength B : 515 ~ 520nm
Wavelength C : 460 ~ 465nm
Wavelength D : N/A
Data Transmission Speed : 800 kHZ
Refresh Rate : 30 FPS
Bit Rate : 48 Bit
Data Clock Frequency : N/A
PWM Dimming Frequency : 8 KHZ
